A1 DC Current Transducer

*Transforms the measured DC current into the 1-way standard DC voltage or DC current output according to linear proportion
*Low power consumption, three isolations, high reliability
*Excellent anti-interference ability and high accuracy (0.2%)
*Current terminals insert, standard din rail(35mm) mounting
*It widely applies to all kinds of industrial current online isolation detection system
*Small size, dimension(mm):95(L)×37(W)×32(H)
*Power supply in 11V~30V can be used universally

Specification

* Standards：IEC688：1992，QB/LF2007-1

* Input Range：0~5A can choose 4~20mA，0~100mA etc

* Accuracy Grade：≤0.2%.F.S

* Temperature Characteristics：≤50PPM/℃(0~50℃)

* Power Consumption：≤30mA+output current

* Working Stability：annual change＜0.2%

* Isolation Withstanding Voltage :AC2.0KV/min*1mA between input/output/power

* Isolation Resistance：≥20MΩ(DC500V)

* Impulse Voltage：5KV(peak value，1.2/50uS

* Response Time：≤300mS

* Load Capacity：1.2 times current continuous

* Working Environment：-10℃~50℃，20%~90% without condensation

* Storage Environment：-40℃~70℃，20%~95% without condensation

Model:

Dimension

Connection:
