Working Condition

Mainly Technology Parameter

Ambient Temperature

-20 ⁰C~80 ⁰C

Max withstand voltage

0.66KV(Can be customized)

Relative Humidity

5~95%

Rated Input

10A~300KA

Altitude

≤3000m

Rated Output

4V,1A (A.C) or 4~20mA（D.C）

No strong vibration site

Accurately Class

0.1%, 0.2%

No strong corrosive gas, steam, or salt in the air Site

Rated Power Supply

±12V、24V、5V D.C Or 220V A.C

Rated Power Consumption

≤10W

Working Frequency

1HZ—1MHZ

No.

Ratio

Input

Output

AC Voltage

DC Current

AC Current

1

10A/4V

10A

4V

4~20mA

0~1A

2

100A/4V

100A

4V

4~20mA

0~1A

3

500A/4V

500A

4V

4~20mA

0~1A

4

3000A/4V

3000A

4V

4~20mA

0~1A

5

10kA/4V

10kA

4V

4~20mA

0~1A

6

25kA/4V

25kA

4V

4~20mA

0~1A

7

60kA/4V

60kA

4V

4~20mA

0~1A

8

80kA/4V

80kA

4V

4~20mA

0~1A

9

150kA/4V

150kA

4V

4~20mA

0~1A

10

300kA/4V

300kA

4V

4~20mA

0~1A
